Motors with high pressure, high-speed drive, and balance valves,
It is designed for high-load conditions
It is the ideal solution for a 6 to 50-ton hydraulic excavator
Efficient and compact design
High-pressure technology increases the efficiency of the hydraulic system
Two-speed motor with integrated balance valve and pressure relief valve
The motor integrates the function of hydraulic braking
Speed can be automatically changed on request
Low temperature, high efficiency
Operating temperature range: -20 ° C~80° C
Compact design
Low displacement high-pressure motors extend the service life of important components and enhance the entire
Durability of system
All-copper liner for hydraulic plunger rotation
Double metal (copper/steel) distribution tray
The rotation combination with a special spring system enhances the life of the motor
The triple sealing system of reducer: mechanical labyrinth seal, V-type oil seal, main oil seal.
The main oil seal can be replaced without disassembling the reducer
The bearings of the reducer are independent components, easy to install, and can be fully preset for negative loads
ITM01:
|
Modal |
(L/min) |
(ML/r) |
(Mpa) |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) |
Rotation |
(℃) |
(mm2/s) |
|
ITM01 |
20 |
6.31/12.56 |
25 |
2-7 |
36.96 |
1845 |
85.8/43 |
bidirectional |
-20-+80 |
16-25 |
|
Modal |
(L/min) |
(ML/r) |
(Mpa) |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) |
Rotation |
(℃) |
(mm2/s) |
|
ITM03 |
40 |
12/18 |
21 |
2-7 |
45.2 |
2719 |
55/37 |
bidirectional |
-20-+80 |
16-25 |
ITM04：
|
Modal |
(L/min) |
(ML/r) Motor |
(Mpa) |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) |
Rotation |
(℃) oil |
(mm2/s) |
|
ITM04 |
40 |
14.3/23.6 |
21 |
2-7 |
52.7 |
4200 |
55/33 |
bidirectional |
-20-+80 |
16-25 |
|
Modal |
(L/min) Input flow |
(ML/r) |
(Mpa) |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) |
Rotation |
(℃) |
(mm2/s) |
|
ITM06 |
50 |
19/34 |
24.5 |
2-7 |
47.53 |
6300 |
55/30 |
bidirectional |
-20- +80 |
16-25 |
|
Modal |
(L/min) Input flow |
(ML/r) |
(Mpa) Working Pressure |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) |
Rotation |
(℃)oil |
(mm2/s) |
|
ITM07 |
50 |
22/44 |
27.5 |
2-7 |
53.706 |
10500 |
50/25 |
bidirectional |
-20-+80 |
16-25 |
ITM09:
|
Modal |
(L/min) |
(ML/r) |
(Mpa) |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) |
Rotation |
(℃) |
(mm2/s) |
|
ITM09 |
80 |
34/53 |
30 |
2-7 |
53.7 |
11500 |
51/33 |
bidirectional |
-20- +80 |
16-25 |
|
Modal |
(L/min) |
(ML/r) |
(Mpa) |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) |
Rotation |
(℃) |
(mm2/s) |
|
ITM10 |
80 |
38/65 |
25 |
2-7 |
53.7 |
13000 |
51/33 |
bidirectional |
-20-+80 |
16-25 |
|
Modal |
(L/min) |
(ML/r) |
(Mpa) |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) |
Rotation |
(℃) |
(mm2/s) |
|
ITM18 |
130 |
43/67 |
30 |
2-7 |
53 |
16900 |
57/37 |
bidirectional |
-20-+80 |
16-25 |
|
Modal |
(L/min) |
(ML/r) |
(Mpa) |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) |
Rotation |
(℃) |
(mm2/s) |
Applicable models |
|
ITM22 |
130 |
48/81 |
34.3 |
2-7 |
53.7 |
23700 |
50/30 |
bidirectional |
-20-+80 |
16-25 |
13-17 |
|
Modal |
(L/min) |
(ML/r) |
(Mpa) |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) Theoretical |
Rotation |
(℃) |
(mm2/s) |
|
ITM40 |
230 |
99/147 |
34.3 |
2-7 |
50.5 |
40546 |
50/32 |
bidirectional |
-20-+80 |
16-25 |
|
Modal |
(L/min) |
(ML/r) |
(Mpa) |
(Mpa) |
Gear ratio |
(N.m) |
(r/min) |
Rotation |
(℃) |
(mm2/s) |
|
ITM60 |
330 |
195/120 |
34.3 |
2-7 |
63.84 |
67000 |
40/26 |
bidirectional |
-20-+80 |
16-25 |
