l*J---C series mooring winch are patent products of our company. They consist of valve blocks with the function of overload protection, hydraulic motor (electromotor with brake), planetary gearbox, belt brake, tooth clutch, drum capstan head, frame, and so on. Due to its fit with the valve block, not only simplified the design of the hydraulic system but also improved the reliability of drives. The winch series could have a CT function if fitted with a constant tension valve bl the series also has high startup efficiency and working efficiency. In addition, compared with traditional mooring the total transmission efficiency of the series is improved by 6~10%and energy loss is lower because of the closed planetary
| Model | IYJ34.54.5-100 / 50-500-24-C-PDX |
IYJ56- -200-500- -38-C-PDLX |
IYJ699-C |
IYJ99-600-1000-50-C-PDLX |
IYJ4611-750/150-240-54-C-PDLX |
IYJK08-50-150-22-PDL |
| Rated working pull 1st layer (KN) |
100/50 |
200 |
350/140 |
600 |
750/150 |
50 |
| Brake support load (KN) |
- |
600 |
500 |
900 |
1250 |
- |
| Speed 1st layer (m/min) |
15/30 |
15.6 |
6/12 |
5 |
5/20
|
20 |
| Drum displacement (mL/r) |
10143.6/5119.2 |
40936 |
75600/37800 |
90744.43 |
103304.35/25826 |
6360.66 |
| System rated pressure (MPa) |
25 |
16 |
26/10.5 |
22 |
31/26 |
15 |
| Diameter of rope (mm) |
24 |
38 |
38 |
50 |
54 |
22 |
| Number of rope layers |
8 |
7 |
5 |
6 |
4 |
7 |
| Capability of drum(m) |
490 |
500 |
500 |
1000 |
240 |
60 |
| Pump flow(L/min) |
90(ηv=0.9) |
300(ηv=0.94) |
162(ηv=0.9) |
139(ηv=0.9) |
178(ηv=0.9) |
79(ηv=0.9) |
| Hydraulic motor type |
A6V107ED22FZ2-054 |
INM5-1450D48011 |
HLA4VSM2500Z-125 |
INM7-3600024011 |
A6VM160HD1D/63W0400VZB080 |
GM3-1000-7D47 |
| Planetary gearbox type | IGT6DW3-B95-A6V107(I=94.8) |
C56(I=28) |
IGC330W3-B302-A4V250(I=302.4) |
6C3302-335-IW7(I=25.13) |
C46611(I=645.65) |
-
|
Products provided by famous enterprises are deeply trusted by users.
Years Industry Experience
Factory Area
Skillful Employees
Advanced Production Line
INI Hydraulic Co., Ltd. has specialized in designing and manufacturing hydraulic winches, hydraulic motors and planetary gearboxes for more than twenty years. We are one of the professional China Anchor Windlass Mooring Winches Suppliers and Anchor Windlass Mooring Winches Factory. Customizing to optimize customers’ ingenious equipment designs is our way to stay alive robustly in the market. Over 26 years, driven by the commitment of always innovating to satisfy customers’ needs, we have developed a wide range of product lines based on our self-developed technologies. The wide spectrum of products, each correlating intimately, contains hydraulic and electric winches, planetary gearboxes, slewing drives, transmission drives, hydraulic motors, pumps and hydraulic systems.
The reliability of our products has been proven strongly in diverse applications, including not limiting industrial machinery, construction machinery, ship & deck machinery, off-shore equipment, mining and metallurgical machinery.
Besides, our product quality has been approved by multiple worldwide renowned certificate bodies. The certifications, that our products have obtained, include EC-Type Examination Certificate, BV MODE, DNV GL Certificate, EC Attestation of Conformity, Certificate of Type Approval for Marine Product and Lloyd’s Register Quality Assurance. So far, besides China, our domestic market, we have widely exported our products to the United States, Germany, the Netherlands, Australia, Russia, Turkey, Singapore, Japan, South Korea, Malaysia, Vietnam, India and Iran. Our logistics and after-sales services cover the whole world promptly and reliably for our customers’ deep interests.
Our products have obtained, include EC-Type Examination Certificate, BV, MODE, DNV, GL Certificate, EC Attestation of Conformity, Certificate of Type Approval for Marine Product and Lloyd’s Register Quality Assurance.
